#include "wined3d_private.h"
#include "wined3d_vk.h"

Include dependency graph for shader_spirv.c:

Classes
struct	shader_spirv_resource_bindings

struct	shader_spirv_priv

struct	shader_spirv_compile_arguments

struct	shader_spirv_graphics_program_variant_vk

struct	shader_spirv_graphics_program_vk

struct	shader_spirv_compute_program_vk

struct	wined3d_shader_spirv_compile_args

struct	wined3d_shader_spirv_shader_interface

Macros
#define	MAX_SM1_INTER_STAGE_VARYINGS 12

Functions
	WINE_DEFAULT_DEBUG_CHANNEL (d3d_shader)

static void	shader_spirv_handle_instruction (const struct wined3d_shader_instruction *ins)

static void	shader_spirv_compile_arguments_init (struct shader_spirv_compile_arguments args, const struct wined3d_context context, const struct wined3d_shader shader, const struct wined3d_state state, unsigned int sample_count)

static void	fill_ps_parameters (struct wined3d_shader_spirv_compile_args vkd3d_args, const struct shader_spirv_compile_arguments compile_args, uint32_t ffp_extra_binding)

static void	shader_spirv_init_compile_args (const struct wined3d_vk_info vk_info, struct wined3d_shader_spirv_compile_args args, struct vkd3d_shader_interface_info vkd3d_interface, enum vkd3d_shader_spirv_environment environment, enum wined3d_shader_type shader_type, enum vkd3d_shader_source_type source_type, const struct shader_spirv_compile_arguments compile_args, const struct shader_spirv_resource_bindings *bindings)

static void	shader_spirv_init_shader_interface_vk (struct wined3d_shader_spirv_shader_interface iface, const struct shader_spirv_resource_bindings b, const struct wined3d_stream_output_desc *so_desc)

static VkShaderModule	shader_spirv_compile_shader (struct wined3d_context_vk context_vk, const struct wined3d_shader_desc shader_desc, enum vkd3d_shader_source_type source_type, enum wined3d_shader_type shader_type, const struct shader_spirv_compile_arguments args, const struct shader_spirv_resource_bindings bindings, const struct wined3d_stream_output_desc *so_desc)

static struct shader_spirv_graphics_program_variant_vk *	shader_spirv_find_graphics_program_variant_vk (struct shader_spirv_priv priv, struct wined3d_context_vk context_vk, struct wined3d_shader shader, const struct wined3d_state state, const struct shader_spirv_resource_bindings *bindings)

static struct shader_spirv_compute_program_vk *	shader_spirv_find_compute_program_vk (struct shader_spirv_priv priv, struct wined3d_context_vk context_vk, struct wined3d_shader shader, const struct shader_spirv_resource_bindings bindings)

static void	shader_spirv_resource_bindings_cleanup (struct shader_spirv_resource_bindings *bindings)

static bool	shader_spirv_resource_bindings_add_vk_binding (struct shader_spirv_resource_bindings bindings, VkDescriptorType vk_type, VkShaderStageFlagBits vk_stage, size_t binding_idx)

static bool	shader_spirv_resource_bindings_add_binding (struct shader_spirv_resource_bindings bindings, enum vkd3d_shader_descriptor_type vkd3d_type, VkDescriptorType vk_type, size_t register_idx, enum vkd3d_shader_visibility vkd3d_visibility, VkShaderStageFlagBits vk_stage, uint32_t flags, size_t binding_idx)

static bool	shader_spirv_resource_bindings_add_uav_counter_binding (struct shader_spirv_resource_bindings bindings, size_t register_idx, enum vkd3d_shader_visibility vkd3d_visibility, VkShaderStageFlagBits vk_stage, size_t binding_idx)

static bool	wined3d_shader_resource_bindings_add_binding (struct wined3d_shader_resource_bindings *bindings, enum wined3d_shader_type shader_type, enum wined3d_shader_descriptor_type shader_descriptor_type, size_t resource_idx, enum wined3d_shader_resource_type resource_type, enum wined3d_data_type resource_data_type, size_t binding_idx)

static VkDescriptorType	vk_descriptor_type_from_vkd3d (enum vkd3d_shader_descriptor_type type, enum vkd3d_shader_resource_type resource_type)

static enum wined3d_shader_descriptor_type	wined3d_descriptor_type_from_vkd3d (enum vkd3d_shader_descriptor_type type)

static enum wined3d_shader_resource_type	wined3d_shader_resource_type_from_vkd3d (enum vkd3d_shader_resource_type t)

static enum wined3d_data_type	wined3d_data_type_from_vkd3d (enum vkd3d_shader_resource_data_type t)

static bool	shader_spirv_resource_bindings_init (struct shader_spirv_resource_bindings bindings, struct wined3d_shader_resource_bindings wined3d_bindings, const struct wined3d_state *state, uint32_t shader_mask)

static void	shader_spirv_scan_shader (struct wined3d_shader shader, struct vkd3d_shader_scan_descriptor_info descriptor_info, struct vkd3d_shader_scan_signature_info *signature_info)

static void	shader_spirv_precompile_compute (struct wined3d_shader *shader)

static void	shader_spirv_precompile (void shader_priv, struct wined3d_shader shader)

static void	shader_spirv_apply_draw_state (void shader_priv, struct wined3d_context context, const struct wined3d_state *state)

static void	shader_spirv_apply_compute_state (void shader_priv, struct wined3d_context context, const struct wined3d_state *state)

static void	shader_spirv_disable (void shader_priv, struct wined3d_context context)

static void	shader_spirv_update_float_vertex_constants (struct wined3d_device *device, UINT start, UINT count)

static void	shader_spirv_update_float_pixel_constants (struct wined3d_device *device, UINT start, UINT count)

static void	shader_spirv_invalidate_compute_program (struct wined3d_context_vk context_vk, const struct shader_spirv_compute_program_vk program)

static void	shader_spirv_invalidate_contexts_compute_program (struct wined3d_device device, const struct shader_spirv_compute_program_vk program)

static void	shader_spirv_invalidate_graphics_program_variant (struct wined3d_context_vk context_vk, const struct shader_spirv_graphics_program_variant_vk variant)

static void	shader_spirv_invalidate_contexts_graphics_program_variant (struct wined3d_device device, const struct shader_spirv_graphics_program_variant_vk variant)

static void	shader_spirv_destroy_compute_vk (struct wined3d_shader *shader)

static void	shader_spirv_destroy (struct wined3d_shader *shader)

static HRESULT	shader_spirv_alloc (struct wined3d_device device, const struct wined3d_vertex_pipe_ops vertex_pipe, const struct wined3d_fragment_pipe_ops *fragment_pipe)

static void	shader_spirv_free (struct wined3d_device device, struct wined3d_context context)

static BOOL	shader_spirv_allocate_context_data (struct wined3d_context *context)

static void	shader_spirv_free_context_data (struct wined3d_context *context)

static void	shader_spirv_init_context_state (struct wined3d_context *context)

static void	shader_spirv_get_caps (const struct wined3d_adapter adapter, struct shader_caps caps)

static BOOL	shader_spirv_color_fixup_supported (struct color_fixup_desc fixup)

static uint64_t	shader_spirv_compile (struct wined3d_context context, const struct wined3d_shader_desc shader_desc, enum wined3d_shader_type shader_type)

const struct wined3d_shader_backend_ops *	wined3d_spirv_shader_backend_init_vk (void)

static void	spirv_vertex_pipe_vk_vp_apply_draw_state (struct wined3d_context context, const struct wined3d_state state)

static void	spirv_vertex_pipe_vk_vp_disable (const struct wined3d_context *context)

static void	spirv_vertex_pipe_vk_vp_get_caps (const struct wined3d_adapter adapter, struct wined3d_vertex_caps caps)

static unsigned int	spirv_vertex_pipe_vk_vp_get_emul_mask (const struct wined3d_adapter *adapter)

static void *	spirv_vertex_pipe_vk_vp_alloc (const struct wined3d_shader_backend_ops shader_backend, void shader_priv)

static void	spirv_vertex_pipe_vk_vp_free (struct wined3d_device device, struct wined3d_context context)

const struct wined3d_vertex_pipe_ops *	wined3d_spirv_vertex_pipe_init_vk (void)

static void	spirv_fragment_pipe_vk_fp_apply_draw_state (struct wined3d_context context, const struct wined3d_state state)

static void	spirv_fragment_pipe_vk_fp_disable (const struct wined3d_context *context)

static void	spirv_fragment_pipe_vk_fp_get_caps (const struct wined3d_adapter adapter, struct fragment_caps caps)

static unsigned int	spirv_fragment_pipe_vk_fp_get_emul_mask (const struct wined3d_adapter *adapter)

static void *	spirv_fragment_pipe_vk_fp_alloc (const struct wined3d_shader_backend_ops shader_backend, void shader_priv)

static void	spirv_fragment_pipe_vk_fp_free (struct wined3d_device device, struct wined3d_context context)

static BOOL	spirv_fragment_pipe_vk_fp_alloc_context_data (struct wined3d_context *context)

static void	spirv_fragment_pipe_vk_fp_free_context_data (struct wined3d_context *context)

const struct wined3d_fragment_pipe_ops *	wined3d_spirv_fragment_pipe_init_vk (void)

Macro Definition Documentation

◆ MAX_SM1_INTER_STAGE_VARYINGS

#define MAX_SM1_INTER_STAGE_VARYINGS 12

Definition at line 58 of file shader_spirv.c.

Function Documentation

◆ fill_ps_parameters()

static void fill_ps_parameters	(	struct wined3d_shader_spirv_compile_args *	vkd3d_args,
		const struct shader_spirv_compile_arguments *	compile_args,
		uint32_t	ffp_extra_binding
	)

static

Definition at line 164 of file shader_spirv.c.

{
    struct vkd3d_shader_parameter1 *parameters = vkd3d_args->parameters;

    parameters[0].name = VKD3D_SHADER_PARAMETER_NAME_RASTERIZER_SAMPLE_COUNT;
    parameters[0].type = VKD3D_SHADER_PARAMETER_TYPE_IMMEDIATE_CONSTANT;
    parameters[0].data_type = VKD3D_SHADER_PARAMETER_DATA_TYPE_UINT32;
    parameters[0].u.immediate_constant.u.u32 = compile_args->u.fs.sample_count;

    parameters[1].name = VKD3D_SHADER_PARAMETER_NAME_FLAT_INTERPOLATION;
    parameters[1].type = VKD3D_SHADER_PARAMETER_TYPE_IMMEDIATE_CONSTANT;
    parameters[1].data_type = VKD3D_SHADER_PARAMETER_DATA_TYPE_UINT32;
    parameters[1].u.immediate_constant.u.u32 = compile_args->u.fs.args.flatshading;

    parameters[2].name = VKD3D_SHADER_PARAMETER_NAME_ALPHA_TEST_FUNC;
    parameters[2].type = VKD3D_SHADER_PARAMETER_TYPE_IMMEDIATE_CONSTANT;
    parameters[2].data_type = VKD3D_SHADER_PARAMETER_DATA_TYPE_UINT32;
    parameters[2].u.immediate_constant.u.u32 = compile_args->u.fs.args.alpha_test_func + 1;

    parameters[3].name = VKD3D_SHADER_PARAMETER_NAME_ALPHA_TEST_REF;
    parameters[3].type = VKD3D_SHADER_PARAMETER_TYPE_BUFFER;
    parameters[3].data_type = VKD3D_SHADER_PARAMETER_DATA_TYPE_FLOAT32;
    parameters[3].u.buffer.set = 0;
    parameters[3].u.buffer.binding = ffp_extra_binding;
    parameters[3].u.buffer.offset = offsetof(struct wined3d_ffp_ps_constants, alpha_test_ref);

    vkd3d_args->parameter_info.parameter_count = 4;
    vkd3d_args->parameter_info.parameters = vkd3d_args->parameters;
}

Referenced by shader_spirv_init_compile_args().

◆ shader_spirv_alloc()

static HRESULT shader_spirv_alloc	(	struct wined3d_device *	device,
		const struct wined3d_vertex_pipe_ops *	vertex_pipe,
		const struct wined3d_fragment_pipe_ops *	fragment_pipe
	)

static

Definition at line 1052 of file shader_spirv.c.

{
    void *vertex_priv, *fragment_priv;
    struct shader_spirv_priv *priv;

    if (!(priv = malloc(sizeof(*priv))))
        return E_OUTOFMEMORY;

    if (!(vertex_priv = vertex_pipe->vp_alloc(&spirv_shader_backend_vk, priv)))
    {
        ERR("Failed to initialise vertex pipe.\n");
        free(priv);
        return E_FAIL;
    }

    if (!(fragment_priv = fragment_pipe->alloc_private(&spirv_shader_backend_vk, priv)))
    {
        ERR("Failed to initialise fragment pipe.\n");
        vertex_pipe->vp_free(device, NULL);
        free(priv);
        return E_FAIL;
    }

    priv->vertex_pipe = vertex_pipe;
    priv->fragment_pipe = fragment_pipe;
    memset(&priv->bindings, 0, sizeof(priv->bindings));

    device->vertex_priv = vertex_priv;
    device->fragment_priv = fragment_priv;
    device->shader_priv = priv;

    return WINED3D_OK;
}

◆ shader_spirv_allocate_context_data()

static BOOL shader_spirv_allocate_context_data ( struct wined3d_context * context )

static

Definition at line 1097 of file shader_spirv.c.

{
    return TRUE;
}

◆ shader_spirv_apply_compute_state()

static void shader_spirv_apply_compute_state	(	void *	shader_priv,
		struct wined3d_context *	context,
		const struct wined3d_state *	state
	)

static

Definition at line 900 of file shader_spirv.c.

{
    struct wined3d_context_vk *context_vk = wined3d_context_vk(context);
    struct shader_spirv_compute_program_vk *program;
    struct shader_spirv_priv *priv = shader_priv;
    struct wined3d_shader *shader;

    if (!shader_spirv_resource_bindings_init(&priv->bindings,
            &context_vk->compute.bindings, state, 1u << WINED3D_SHADER_TYPE_COMPUTE))
        ERR("Failed to initialise shader resource bindings.\n");

    if ((shader = state->shader[WINED3D_SHADER_TYPE_COMPUTE]))
        program = shader_spirv_find_compute_program_vk(priv, context_vk, shader, &priv->bindings);
    else
        program = NULL;

    if (program)
    {
        context_vk->compute.vk_pipeline = program->vk_pipeline;
        context_vk->compute.vk_set_layout = program->vk_set_layout;
        context_vk->compute.vk_pipeline_layout = program->vk_pipeline_layout;
    }
    else
    {
        context_vk->compute.vk_pipeline = VK_NULL_HANDLE;
        context_vk->compute.vk_set_layout = VK_NULL_HANDLE;
        context_vk->compute.vk_pipeline_layout = VK_NULL_HANDLE;
    }
}

◆ shader_spirv_apply_draw_state()

static void shader_spirv_apply_draw_state	(	void *	shader_priv,
		struct wined3d_context *	context,
		const struct wined3d_state *	state
	)

static

Definition at line 846 of file shader_spirv.c.

{
    struct wined3d_context_vk *context_vk = wined3d_context_vk(context);
    struct shader_spirv_graphics_program_variant_vk *variant_vk;
    struct shader_spirv_resource_bindings *bindings;
    size_t binding_base[WINED3D_SHADER_TYPE_COUNT];
    struct wined3d_pipeline_layout_vk *layout_vk;
    struct shader_spirv_priv *priv = shader_priv;
    enum wined3d_shader_type shader_type;
    struct wined3d_shader *shader;

    priv->vertex_pipe->vp_apply_draw_state(context, state);
    priv->fragment_pipe->fp_apply_draw_state(context, state);

    bindings = &priv->bindings;
    memcpy(binding_base, bindings->binding_base, sizeof(bindings->binding_base));
    if (!shader_spirv_resource_bindings_init(bindings, &context_vk->graphics.bindings,
            state, ~(1u << WINED3D_SHADER_TYPE_COMPUTE)))
    {
        ERR("Failed to initialise shader resource bindings.\n");
        goto fail;
    }
    if (context->shader_update_mask & (1u << WINED3D_SHADER_TYPE_GEOMETRY))
        context->shader_update_mask |= 1u << bindings->so_stage;

    layout_vk = wined3d_context_vk_get_pipeline_layout(context_vk, bindings->vk_bindings, bindings->vk_binding_count);
    context_vk->graphics.vk_set_layout = layout_vk->vk_set_layout;
    context_vk->graphics.vk_pipeline_layout = layout_vk->vk_pipeline_layout;

    for (shader_type = 0; shader_type < ARRAY_SIZE(context_vk->graphics.vk_modules); ++shader_type)
    {
        if (!(context->shader_update_mask & (1u << shader_type)) && (!context_vk->graphics.vk_modules[shader_type]
                || binding_base[shader_type] == bindings->binding_base[shader_type]))
            continue;

        if (!(shader = state->shader[shader_type]) || !shader->function)
        {
            context_vk->graphics.vk_modules[shader_type] = VK_NULL_HANDLE;
            continue;
        }

        if (!(variant_vk = shader_spirv_find_graphics_program_variant_vk(priv, context_vk, shader, state, bindings)))
            goto fail;
        context_vk->graphics.vk_modules[shader_type] = variant_vk->vk_module;
    }

    return;

fail:
    context_vk->graphics.vk_set_layout = VK_NULL_HANDLE;
    context_vk->graphics.vk_pipeline_layout = VK_NULL_HANDLE;
}

◆ shader_spirv_color_fixup_supported()

static BOOL shader_spirv_color_fixup_supported ( struct color_fixup_desc fixup )

static

Definition at line 1128 of file shader_spirv.c.

{
    return is_identity_fixup(fixup);
}

◆ shader_spirv_compile()

static uint64_t shader_spirv_compile	(	struct wined3d_context *	context,
		const struct wined3d_shader_desc *	shader_desc,
		enum wined3d_shader_type	shader_type
	)

static

Definition at line 1133 of file shader_spirv.c.

{
    struct shader_spirv_resource_bindings bindings = {0};
    return (uint64_t)shader_spirv_compile_shader(wined3d_context_vk(context), shader_desc,
            VKD3D_SHADER_SOURCE_DXBC_TPF, shader_type, NULL, &bindings, NULL);
}

◆ shader_spirv_compile_arguments_init()

static void shader_spirv_compile_arguments_init	(	struct shader_spirv_compile_arguments *	args,
		const struct wined3d_context *	context,
		const struct wined3d_shader *	shader,
		const struct wined3d_state *	state,
		unsigned int	sample_count
	)

static

Definition at line 125 of file shader_spirv.c.

{
    memset(args, 0, sizeof(*args));

    switch (shader->reg_maps.shader_version.type)
    {
        case WINED3D_SHADER_TYPE_PIXEL:
            /* The context here doesn't have a valid stream info, but that's
             * fine, because we have full_ffp_varyings. */
            find_ps_compile_args(state, shader,
                    state->vertex_declaration && state->vertex_declaration->position_transformed,
                    &args->u.fs.args, context);
            args->u.fs.sample_count = sample_count;
            break;

        case WINED3D_SHADER_TYPE_VERTEX:
        {
            struct wined3d_shader *ps = state->shader[WINED3D_SHADER_TYPE_PIXEL];

            if (shader->reg_maps.shader_version.major < 4 && ps)
            {
                struct shader_spirv_graphics_program_vk *vs_program = shader->backend_data;
                struct shader_spirv_graphics_program_vk *ps_program = ps->backend_data;

                if (ps_program->signature_info.input.element_count > ARRAY_SIZE(args->u.vs.varying_map))
                    ERR("Unexpected inter-stage varying count %u.\n", ps_program->signature_info.input.element_count);
                vkd3d_shader_build_varying_map(&vs_program->signature_info.output,
                        &ps_program->signature_info.input, &args->u.vs.varying_count, args->u.vs.varying_map);
            }
            break;
        }

        default:
            break;
    }
}

Referenced by shader_spirv_find_graphics_program_variant_vk().

◆ shader_spirv_compile_shader()

static VkShaderModule shader_spirv_compile_shader	(	struct wined3d_context_vk *	context_vk,
		const struct wined3d_shader_desc *	shader_desc,
		enum vkd3d_shader_source_type	source_type,
		enum wined3d_shader_type	shader_type,
		const struct shader_spirv_compile_arguments *	args,
		const struct shader_spirv_resource_bindings *	bindings,
		const struct wined3d_stream_output_desc *	so_desc
	)

static

Definition at line 278 of file shader_spirv.c.

{
    struct wined3d_device_vk *device_vk = wined3d_device_vk(context_vk->c.device);
    const struct wined3d_vk_info *vk_info = &device_vk->vk_info;
    struct wined3d_shader_spirv_compile_args compile_args;
    struct wined3d_shader_spirv_shader_interface iface;
    VkShaderModuleCreateInfo shader_create_info;
    struct vkd3d_shader_compile_info info;
    struct vkd3d_shader_code spirv;
    VkShaderModule module;
    char *messages;
    VkResult vr;
    int ret;

    shader_spirv_init_shader_interface_vk(&iface, bindings, so_desc);
    shader_spirv_init_compile_args(vk_info, &compile_args, &iface.vkd3d_interface,
            VKD3D_SHADER_SPIRV_ENVIRONMENT_VULKAN_1_0, shader_type, source_type, args, bindings);

    info.type = VKD3D_SHADER_STRUCTURE_TYPE_COMPILE_INFO;
    info.next = &compile_args.spirv_target;
    info.source.code = shader_desc->byte_code;
    info.source.size = shader_desc->byte_code_size;
    info.source_type = source_type;
    info.target_type = VKD3D_SHADER_TARGET_SPIRV_BINARY;
    info.options = spirv_compile_options;
    info.option_count = ARRAY_SIZE(spirv_compile_options);
    info.log_level = VKD3D_SHADER_LOG_WARNING;
    info.source_name = NULL;

    ret = vkd3d_shader_compile(&info, &spirv, &messages);
    if (messages && *messages && FIXME_ON(d3d_shader))
    {
        const char *ptr, *end, *line;

        FIXME("Shader log:\n");
        ptr = messages;
        end = ptr + strlen(ptr);
        while ((line = wined3d_get_line(&ptr, end)))
        {
            FIXME("    %.*s", (int)(ptr - line), line);
        }
        FIXME("\n");
    }
    vkd3d_shader_free_messages(messages);

    if (ret < 0)
    {
        ERR("Failed to compile shader, ret %d.\n", ret);
        return VK_NULL_HANDLE;
    }

    shader_create_info.sType = VK_STRUCTURE_TYPE_SHADER_MODULE_CREATE_INFO;
    shader_create_info.pNext = NULL;
    shader_create_info.flags = 0;
    shader_create_info.codeSize = spirv.size;
    shader_create_info.pCode = spirv.code;
    if ((vr = VK_CALL(vkCreateShaderModule(device_vk->vk_device, &shader_create_info, NULL, &module))) < 0)
    {
        vkd3d_shader_free_shader_code(&spirv);
        WARN("Failed to create Vulkan shader module, vr %s.\n", wined3d_debug_vkresult(vr));
        return VK_NULL_HANDLE;
    }

    vkd3d_shader_free_shader_code(&spirv);

    return module;
}

Referenced by shader_spirv_compile(), shader_spirv_find_compute_program_vk(), and shader_spirv_find_graphics_program_variant_vk().

◆ shader_spirv_destroy()

static void shader_spirv_destroy ( struct wined3d_shader * shader )

static

Definition at line 1020 of file shader_spirv.c.

{
    struct wined3d_device_vk *device_vk = wined3d_device_vk(shader->device);
    struct shader_spirv_graphics_program_variant_vk *variant_vk;
    struct wined3d_vk_info *vk_info = &device_vk->vk_info;
    struct shader_spirv_graphics_program_vk *program_vk;
    size_t i;

    if (!shader->backend_data)
        return;

    if (shader->reg_maps.shader_version.type == WINED3D_SHADER_TYPE_COMPUTE)
    {
        shader_spirv_destroy_compute_vk(shader);
        return;
    }

    program_vk = shader->backend_data;
    for (i = 0; i < program_vk->variant_count; ++i)
    {
        variant_vk = &program_vk->variants[i];
        shader_spirv_invalidate_contexts_graphics_program_variant(&device_vk->d, variant_vk);
        VK_CALL(vkDestroyShaderModule(device_vk->vk_device, variant_vk->vk_module, NULL));
    }
    free(program_vk->variants);
    vkd3d_shader_free_scan_descriptor_info(&program_vk->descriptor_info);
    vkd3d_shader_free_scan_signature_info(&program_vk->signature_info);

    shader->backend_data = NULL;
    free(program_vk);
}

◆ shader_spirv_destroy_compute_vk()

static void shader_spirv_destroy_compute_vk ( struct wined3d_shader * shader )

static

Definition at line 1005 of file shader_spirv.c.

{
    struct wined3d_device_vk *device_vk = wined3d_device_vk(shader->device);
    struct shader_spirv_compute_program_vk *program = shader->backend_data;
    struct wined3d_context_vk *context_vk = &device_vk->context_vk;
    struct wined3d_vk_info *vk_info = &device_vk->vk_info;

    shader_spirv_invalidate_contexts_compute_program(&device_vk->d, program);
    wined3d_context_vk_destroy_vk_pipeline(context_vk, program->vk_pipeline, context_vk->current_command_buffer.id);
    VK_CALL(vkDestroyShaderModule(device_vk->vk_device, program->vk_module, NULL));
    vkd3d_shader_free_scan_descriptor_info(&program->descriptor_info);
    shader->backend_data = NULL;
    free(program);
}

Referenced by shader_spirv_destroy().

◆ shader_spirv_disable()

static void shader_spirv_disable	(	void *	shader_priv,
		struct wined3d_context *	context
	)

static

Definition at line 931 of file shader_spirv.c.

{
    struct wined3d_context_vk *context_vk = wined3d_context_vk(context);
    struct shader_spirv_priv *priv = shader_priv;

    priv->vertex_pipe->vp_disable(context);
    priv->fragment_pipe->fp_disable(context);

    context_vk->compute.vk_pipeline = VK_NULL_HANDLE;
    context->shader_update_mask = (1u << WINED3D_SHADER_TYPE_PIXEL)
            | (1u << WINED3D_SHADER_TYPE_VERTEX)
            | (1u << WINED3D_SHADER_TYPE_GEOMETRY)
            | (1u << WINED3D_SHADER_TYPE_HULL)
            | (1u << WINED3D_SHADER_TYPE_DOMAIN)
            | (1u << WINED3D_SHADER_TYPE_COMPUTE);
}

◆ shader_spirv_find_compute_program_vk()

static struct shader_spirv_compute_program_vk * shader_spirv_find_compute_program_vk	(	struct shader_spirv_priv *	priv,
		struct wined3d_context_vk *	context_vk,
		struct wined3d_shader *	shader,
		const struct shader_spirv_resource_bindings *	bindings
	)

static

Definition at line 405 of file shader_spirv.c.

{
    struct wined3d_device_vk *device_vk = wined3d_device_vk(context_vk->c.device);
    const struct wined3d_vk_info *vk_info = context_vk->vk_info;
    struct shader_spirv_compute_program_vk *program;
    struct wined3d_pipeline_layout_vk *layout;
    VkComputePipelineCreateInfo pipeline_info;
    struct wined3d_shader_desc shader_desc;
    VkResult vr;

    if (!(program = shader->backend_data))
        return NULL;

    if (program->vk_module)
        return program;

    shader_desc.byte_code = shader->byte_code;
    shader_desc.byte_code_size = shader->byte_code_size;

    if (!(program->vk_module = shader_spirv_compile_shader(context_vk, &shader_desc,
            shader->source_type, WINED3D_SHADER_TYPE_COMPUTE, NULL, bindings, NULL)))
        return NULL;

    if (!(layout = wined3d_context_vk_get_pipeline_layout(context_vk,
            bindings->vk_bindings, bindings->vk_binding_count)))
    {
        VK_CALL(vkDestroyShaderModule(device_vk->vk_device, program->vk_module, NULL));
        program->vk_module = VK_NULL_HANDLE;
        return NULL;
    }
    program->vk_set_layout = layout->vk_set_layout;
    program->vk_pipeline_layout = layout->vk_pipeline_layout;

    pipeline_info.sType = VK_STRUCTURE_TYPE_COMPUTE_PIPELINE_CREATE_INFO;
    pipeline_info.pNext = NULL;
    pipeline_info.flags = 0;
    pipeline_info.stage.sType = VK_STRUCTURE_TYPE_PIPELINE_SHADER_STAGE_CREATE_INFO;
    pipeline_info.stage.pNext = NULL;
    pipeline_info.stage.flags = 0;
    pipeline_info.stage.stage = VK_SHADER_STAGE_COMPUTE_BIT;
    pipeline_info.stage.pName = "main";
    pipeline_info.stage.pSpecializationInfo = NULL;
    pipeline_info.stage.module = program->vk_module;
    pipeline_info.layout = program->vk_pipeline_layout;
    pipeline_info.basePipelineHandle = VK_NULL_HANDLE;
    pipeline_info.basePipelineIndex = -1;
    if ((vr = VK_CALL(vkCreateComputePipelines(device_vk->vk_device,
            VK_NULL_HANDLE, 1, &pipeline_info, NULL, &program->vk_pipeline))) < 0)
    {
        ERR("Failed to create Vulkan compute pipeline, vr %s.\n", wined3d_debug_vkresult(vr));
        VK_CALL(vkDestroyShaderModule(device_vk->vk_device, program->vk_module, NULL));
        program->vk_module = VK_NULL_HANDLE;
        return NULL;
    }

    return program;
}

Referenced by shader_spirv_apply_compute_state().

◆ shader_spirv_find_graphics_program_variant_vk()

static struct shader_spirv_graphics_program_variant_vk * shader_spirv_find_graphics_program_variant_vk	(	struct shader_spirv_priv *	priv,
		struct wined3d_context_vk *	context_vk,
		struct wined3d_shader *	shader,
		const struct wined3d_state *	state,
		const struct shader_spirv_resource_bindings *	bindings
	)

static

Definition at line 349 of file shader_spirv.c.

{
    enum wined3d_shader_type shader_type = shader->reg_maps.shader_version.type;
    struct shader_spirv_graphics_program_variant_vk *variant_vk;
    size_t binding_base = bindings->binding_base[shader_type];
    const struct wined3d_stream_output_desc *so_desc = NULL;
    struct shader_spirv_graphics_program_vk *program_vk;
    struct shader_spirv_compile_arguments args;
    struct wined3d_shader_desc shader_desc;
    size_t variant_count, i;

    shader_spirv_compile_arguments_init(&args, &context_vk->c, shader, state, context_vk->sample_count);
    if (bindings->so_stage == shader_type)
        so_desc = state->shader[WINED3D_SHADER_TYPE_GEOMETRY]->u.gs.so_desc;

    if (!(program_vk = shader->backend_data))
        return NULL;

    variant_count = program_vk->variant_count;
    for (i = 0; i < variant_count; ++i)
    {
        variant_vk = &program_vk->variants[i];
        if (variant_vk->so_desc == so_desc && variant_vk->binding_base == binding_base
                && !memcmp(&variant_vk->compile_args, &args, sizeof(args)))
            return variant_vk;
    }

    if (!wined3d_array_reserve((void **)&program_vk->variants, &program_vk->variants_size,
            variant_count + 1, sizeof(*program_vk->variants)))
        return NULL;

    variant_vk = &program_vk->variants[variant_count];
    variant_vk->compile_args = args;
    variant_vk->binding_base = binding_base;

    if (shader->source_type == VKD3D_SHADER_SOURCE_D3D_BYTECODE)
    {
        shader_desc.byte_code = shader->function;
        shader_desc.byte_code_size = shader->functionLength;
    }
    else
    {
        shader_desc.byte_code = shader->byte_code;
        shader_desc.byte_code_size = shader->byte_code_size;
    }

    if (!(variant_vk->vk_module = shader_spirv_compile_shader(context_vk, &shader_desc,
            shader->source_type, shader_type, &args, bindings, so_desc)))
        return NULL;
    ++program_vk->variant_count;

    return variant_vk;
}

Referenced by shader_spirv_apply_draw_state().

◆ shader_spirv_free()

static void shader_spirv_free	(	struct wined3d_device *	device,
		struct wined3d_context *	context
	)

static

Definition at line 1087 of file shader_spirv.c.

{
    struct shader_spirv_priv *priv = device->shader_priv;

    shader_spirv_resource_bindings_cleanup(&priv->bindings);
    priv->fragment_pipe->free_private(device, context);
    priv->vertex_pipe->vp_free(device, context);
    free(priv);
}

◆ shader_spirv_free_context_data()

static void shader_spirv_free_context_data ( struct wined3d_context * context )

static

Definition at line 1102 of file shader_spirv.c.

1103{

1104}

◆ shader_spirv_get_caps()

static void shader_spirv_get_caps	(	const struct wined3d_adapter *	adapter,
		struct shader_caps *	caps
	)

static

Definition at line 1110 of file shader_spirv.c.

{
    memset(caps, 0, sizeof(*caps));

    caps->vs_version = min(wined3d_settings.max_sm_vs, 5);
    caps->hs_version = min(wined3d_settings.max_sm_hs, 5);
    caps->ds_version = min(wined3d_settings.max_sm_ds, 5);
    caps->gs_version = min(wined3d_settings.max_sm_gs, 5);
    caps->ps_version = min(wined3d_settings.max_sm_ps, 5);
    caps->cs_version = min(wined3d_settings.max_sm_cs, 5);

    caps->vs_uniform_count = WINED3D_MAX_VS_CONSTS_F;
    caps->ps_uniform_count = WINED3D_MAX_PS_CONSTS_F;
    caps->ps_1x_max_value = FLT_MAX;
    caps->varying_count = 0;
    caps->wined3d_caps = WINED3D_SHADER_CAP_FULL_FFP_VARYINGS;
}

◆ shader_spirv_handle_instruction()

static void shader_spirv_handle_instruction ( const struct wined3d_shader_instruction * ins )

static

Definition at line 121 of file shader_spirv.c.

122{

123}

◆ shader_spirv_init_compile_args()

static void shader_spirv_init_compile_args	(	const struct wined3d_vk_info *	vk_info,
		struct wined3d_shader_spirv_compile_args *	args,
		struct vkd3d_shader_interface_info *	vkd3d_interface,
		enum vkd3d_shader_spirv_environment	environment,
		enum wined3d_shader_type	shader_type,
		enum vkd3d_shader_source_type	source_type,
		const struct shader_spirv_compile_arguments *	compile_args,
		const struct shader_spirv_resource_bindings *	bindings
	)

static

Definition at line 195 of file shader_spirv.c.

{
    unsigned int i;

    memset(args, 0, sizeof(*args));
    args->spirv_target.type = VKD3D_SHADER_STRUCTURE_TYPE_SPIRV_TARGET_INFO;
    args->spirv_target.next = &args->parameter_info;
    args->spirv_target.entry_point = "main";
    args->spirv_target.environment = environment;

    args->parameter_info.type = VKD3D_SHADER_STRUCTURE_TYPE_PARAMETER_INFO;
    args->parameter_info.next = vkd3d_interface;

    args->spirv_target.extensions = args->extensions;

    if (vk_info->supported[WINED3D_VK_EXT_SHADER_STENCIL_EXPORT])
        args->extensions[args->spirv_target.extension_count++] = VKD3D_SHADER_SPIRV_EXTENSION_EXT_STENCIL_EXPORT;
    assert(args->spirv_target.extension_count <= ARRAY_SIZE(args->extensions));

    if (shader_type == WINED3D_SHADER_TYPE_PIXEL)
    {
        unsigned int rt_alpha_swizzle = compile_args->u.fs.args.rt_alpha_swizzle;

        fill_ps_parameters(args, compile_args, bindings->ffp_extra_binding[WINED3D_SHADER_TYPE_PIXEL]);

        args->spirv_target.dual_source_blending = compile_args->u.fs.args.dual_source_blend;

        for (i = 0; i < ARRAY_SIZE(args->ps_alpha_swizzle); ++i)
        {
            if (rt_alpha_swizzle && (1u << i))
                args->ps_alpha_swizzle[i] = VKD3D_SHADER_SWIZZLE(W, X, Y, Z);
            else
                args->ps_alpha_swizzle[i] = VKD3D_SHADER_NO_SWIZZLE;
        }

        args->spirv_target.output_swizzles = args->ps_alpha_swizzle;
        args->spirv_target.output_swizzle_count = ARRAY_SIZE(args->ps_alpha_swizzle);
    }
    else if (shader_type == WINED3D_SHADER_TYPE_VERTEX)
    {
        if (source_type == VKD3D_SHADER_SOURCE_D3D_BYTECODE)
        {
            args->spirv_target.next = &args->varying_map;

            args->varying_map.type = VKD3D_SHADER_STRUCTURE_TYPE_VARYING_MAP_INFO;
            args->varying_map.next = vkd3d_interface;
            args->varying_map.varying_map = compile_args->u.vs.varying_map;
            args->varying_map.varying_count = compile_args->u.vs.varying_count;
        }
    }
}

Referenced by shader_spirv_compile_shader().

◆ shader_spirv_init_context_state()

static void shader_spirv_init_context_state ( struct wined3d_context * context )

static

Definition at line 1106 of file shader_spirv.c.

1107{

1108}

◆ shader_spirv_init_shader_interface_vk()

static void shader_spirv_init_shader_interface_vk	(	struct wined3d_shader_spirv_shader_interface *	iface,
		const struct shader_spirv_resource_bindings *	b,
		const struct wined3d_stream_output_desc *	so_desc
	)

static

Definition at line 252 of file shader_spirv.c.

{
    memset(iface, 0, sizeof(*iface));
    iface->vkd3d_interface.type = VKD3D_SHADER_STRUCTURE_TYPE_INTERFACE_INFO;

    if (so_desc)
    {
        iface->xfb_info.type = VKD3D_SHADER_STRUCTURE_TYPE_TRANSFORM_FEEDBACK_INFO;
        iface->xfb_info.next = NULL;

        iface->xfb_info.elements = (const struct vkd3d_shader_transform_feedback_element *)so_desc->elements;
        iface->xfb_info.element_count = so_desc->element_count;
        iface->xfb_info.buffer_strides = so_desc->buffer_strides;
        iface->xfb_info.buffer_stride_count = so_desc->buffer_stride_count;

        iface->vkd3d_interface.next = &iface->xfb_info;
    }

    iface->vkd3d_interface.bindings = b->bindings;
    iface->vkd3d_interface.binding_count = b->binding_count;

    iface->vkd3d_interface.uav_counters = b->uav_counters;
    iface->vkd3d_interface.uav_counter_count = b->uav_counter_count;
}

Referenced by shader_spirv_compile_shader().

◆ shader_spirv_invalidate_compute_program()

static void shader_spirv_invalidate_compute_program	(	struct wined3d_context_vk *	context_vk,
		const struct shader_spirv_compute_program_vk *	program
	)

static

Definition at line 958 of file shader_spirv.c.

{
    if (context_vk->compute.vk_pipeline == program->vk_pipeline)
    {
        context_vk->c.shader_update_mask |= (1u << WINED3D_SHADER_TYPE_COMPUTE);
        context_vk->compute.vk_pipeline = VK_NULL_HANDLE;
    }
}

Referenced by shader_spirv_invalidate_contexts_compute_program().

◆ shader_spirv_invalidate_contexts_compute_program()

static void shader_spirv_invalidate_contexts_compute_program	(	struct wined3d_device *	device,
		const struct shader_spirv_compute_program_vk *	program
	)

static

Definition at line 968 of file shader_spirv.c.

{
    unsigned int i;

    for (i = 0; i < device->context_count; ++i)
    {
        shader_spirv_invalidate_compute_program(wined3d_context_vk(device->contexts[i]), program);
    }
}

Referenced by shader_spirv_destroy_compute_vk().

◆ shader_spirv_invalidate_contexts_graphics_program_variant()

static void shader_spirv_invalidate_contexts_graphics_program_variant	(	struct wined3d_device *	device,
		const struct shader_spirv_graphics_program_variant_vk *	variant
	)

static

Definition at line 994 of file shader_spirv.c.

{
    unsigned int i;

    for (i = 0; i < device->context_count; ++i)
    {
        shader_spirv_invalidate_graphics_program_variant(wined3d_context_vk(device->contexts[i]), variant);
    }
}

Referenced by shader_spirv_destroy().

◆ shader_spirv_invalidate_graphics_program_variant()

static void shader_spirv_invalidate_graphics_program_variant	(	struct wined3d_context_vk *	context_vk,
		const struct shader_spirv_graphics_program_variant_vk *	variant
	)

static

Definition at line 979 of file shader_spirv.c.

{
    enum wined3d_shader_type shader_type;

    for (shader_type = 0; shader_type < WINED3D_SHADER_TYPE_GRAPHICS_COUNT; ++shader_type)
    {
        if (context_vk->graphics.vk_modules[shader_type] != variant->vk_module)
            continue;

        context_vk->graphics.vk_modules[shader_type] = VK_NULL_HANDLE;
        context_vk->c.shader_update_mask |= (1u << shader_type);
    }
}

Referenced by shader_spirv_invalidate_contexts_graphics_program_variant().

◆ shader_spirv_precompile()

static void shader_spirv_precompile	(	void *	shader_priv,
		struct wined3d_shader *	shader
	)

static

Definition at line 824 of file shader_spirv.c.

{
    struct shader_spirv_graphics_program_vk *program_vk;

    TRACE("shader_priv %p, shader %p.\n", shader_priv, shader);

    if (shader->reg_maps.shader_version.type == WINED3D_SHADER_TYPE_COMPUTE)
    {
        shader_spirv_precompile_compute(shader);
        return;
    }

    if (!(program_vk = shader->backend_data))
    {
        if (!(program_vk = calloc(1, sizeof(*program_vk))))
            ERR("Failed to allocate program.\n");
        shader->backend_data = program_vk;
    }

    shader_spirv_scan_shader(shader, &program_vk->descriptor_info, &program_vk->signature_info);
}

◆ shader_spirv_precompile_compute()

static void shader_spirv_precompile_compute ( struct wined3d_shader * shader )

static

Definition at line 810 of file shader_spirv.c.

{
    struct shader_spirv_compute_program_vk *program_vk;

    if (!(program_vk = shader->backend_data))
    {
        if (!(program_vk = calloc(1, sizeof(*program_vk))))
            ERR("Failed to allocate program.\n");
        shader->backend_data = program_vk;
    }

    shader_spirv_scan_shader(shader, &program_vk->descriptor_info, NULL);
}

Referenced by shader_spirv_precompile().

◆ shader_spirv_resource_bindings_add_binding()

static bool shader_spirv_resource_bindings_add_binding	(	struct shader_spirv_resource_bindings *	bindings,
		enum vkd3d_shader_descriptor_type	vkd3d_type,
		VkDescriptorType	vk_type,
		size_t	register_idx,
		enum vkd3d_shader_visibility	vkd3d_visibility,
		VkShaderStageFlagBits	vk_stage,
		uint32_t	flags,
		size_t *	binding_idx
	)

static

Definition at line 493 of file shader_spirv.c.

{
    SIZE_T binding_count = bindings->binding_count;
    struct vkd3d_shader_resource_binding *binding;

    if (!wined3d_array_reserve((void **)&bindings->bindings, &bindings->bindings_size,
            binding_count + 1, sizeof(*bindings->bindings)))
        return false;

    if (!shader_spirv_resource_bindings_add_vk_binding(bindings, vk_type, vk_stage, binding_idx))
        return false;

    binding = &bindings->bindings[binding_count];
    binding->type = vkd3d_type;
    binding->register_space = 0;
    binding->register_index = register_idx;
    binding->shader_visibility = vkd3d_visibility;
    binding->flags = flags;
    binding->binding.set = 0;
    binding->binding.binding = *binding_idx;
    binding->binding.count = 1;
    ++bindings->binding_count;

    return true;
}

Referenced by shader_spirv_resource_bindings_init().

◆ shader_spirv_resource_bindings_add_uav_counter_binding()

static bool shader_spirv_resource_bindings_add_uav_counter_binding	(	struct shader_spirv_resource_bindings *	bindings,
		size_t	register_idx,
		enum vkd3d_shader_visibility	vkd3d_visibility,
		VkShaderStageFlagBits	vk_stage,
		size_t *	binding_idx
	)

static

Definition at line 522 of file shader_spirv.c.

{
    SIZE_T uav_counter_count = bindings->uav_counter_count;
    struct vkd3d_shader_uav_counter_binding *counter;

    if (uav_counter_count >= ARRAY_SIZE(bindings->uav_counters))
        return false;

    if (!shader_spirv_resource_bindings_add_vk_binding(bindings,
            VK_DESCRIPTOR_TYPE_STORAGE_TEXEL_BUFFER, vk_stage, binding_idx))
        return false;

    counter = &bindings->uav_counters[uav_counter_count];
    counter->register_space = 0;
    counter->register_index = register_idx;
    counter->shader_visibility = vkd3d_visibility;
    counter->binding.set = 0;
    counter->binding.binding = *binding_idx;
    counter->binding.count = 1;
    counter->offset = 0;
    ++bindings->uav_counter_count;

    return true;
}

Referenced by shader_spirv_resource_bindings_init().

◆ shader_spirv_resource_bindings_add_vk_binding()

static bool shader_spirv_resource_bindings_add_vk_binding	(	struct shader_spirv_resource_bindings *	bindings,
		VkDescriptorType	vk_type,
		VkShaderStageFlagBits	vk_stage,
		size_t *	binding_idx
	)

static

Definition at line 471 of file shader_spirv.c.

{
    SIZE_T binding_count = bindings->vk_binding_count;
    VkDescriptorSetLayoutBinding *binding;

    if (!wined3d_array_reserve((void **)&bindings->vk_bindings, &bindings->vk_bindings_size,
            binding_count + 1, sizeof(*bindings->vk_bindings)))
        return false;

    *binding_idx = binding_count;
    binding = &bindings->vk_bindings[binding_count];
    binding->binding = binding_count;
    binding->descriptorType = vk_type;
    binding->descriptorCount = 1;
    binding->stageFlags = vk_stage;
    binding->pImmutableSamplers = NULL;
    ++bindings->vk_binding_count;

    return true;
}

Referenced by shader_spirv_resource_bindings_add_binding(), and shader_spirv_resource_bindings_add_uav_counter_binding().

◆ shader_spirv_resource_bindings_cleanup()

static void shader_spirv_resource_bindings_cleanup ( struct shader_spirv_resource_bindings * bindings )

static

Definition at line 465 of file shader_spirv.c.

{
    free(bindings->vk_bindings);
    free(bindings->bindings);
}

Referenced by shader_spirv_free().

◆ shader_spirv_resource_bindings_init()

static bool shader_spirv_resource_bindings_init	(	struct shader_spirv_resource_bindings *	bindings,
		struct wined3d_shader_resource_bindings *	wined3d_bindings,
		const struct wined3d_state *	state,
		uint32_t	shader_mask
	)

static

Definition at line 649 of file shader_spirv.c.

{
    const struct vkd3d_shader_scan_descriptor_info *descriptor_info;
    enum wined3d_shader_descriptor_type wined3d_type;
    enum vkd3d_shader_visibility shader_visibility;
    enum wined3d_shader_type shader_type;
    VkDescriptorType vk_descriptor_type;
    VkShaderStageFlagBits vk_stage;
    struct wined3d_shader *shader;
    size_t binding_idx;
    unsigned int i;

    bindings->binding_count = 0;
    bindings->uav_counter_count = 0;
    bindings->vk_binding_count = 0;
    bindings->so_stage = WINED3D_SHADER_TYPE_GEOMETRY;
    wined3d_bindings->count = 0;

    for (shader_type = 0; shader_type < WINED3D_SHADER_TYPE_COUNT; ++shader_type)
    {
        bindings->binding_base[shader_type] = bindings->vk_binding_count;

        if (!(shader_mask & (1u << shader_type)) || !(shader = state->shader[shader_type]))
            continue;

        if (shader_type == WINED3D_SHADER_TYPE_COMPUTE)
        {
            descriptor_info = &((struct shader_spirv_compute_program_vk *)shader->backend_data)->descriptor_info;
        }
        else
        {
            descriptor_info = &((struct shader_spirv_graphics_program_vk *)shader->backend_data)->descriptor_info;
            if (shader_type == WINED3D_SHADER_TYPE_GEOMETRY && !shader->function)
                bindings->so_stage = WINED3D_SHADER_TYPE_VERTEX;
        }

        vk_stage = vk_shader_stage_from_wined3d(shader_type);
        shader_visibility = vkd3d_shader_visibility_from_wined3d(shader_type);

        for (i = 0; i < descriptor_info->descriptor_count; ++i)
        {
            const struct vkd3d_shader_descriptor_info *d = &descriptor_info->descriptors[i];
            uint32_t flags;

            if (d->register_space)
            {
                WARN("Unsupported register space %u.\n", d->register_space);
                return false;
            }

            if (d->resource_type == VKD3D_SHADER_RESOURCE_BUFFER)
                flags = VKD3D_SHADER_BINDING_FLAG_BUFFER;
            else
                flags = VKD3D_SHADER_BINDING_FLAG_IMAGE;

            vk_descriptor_type = vk_descriptor_type_from_vkd3d(d->type, d->resource_type);
            if (!shader_spirv_resource_bindings_add_binding(bindings, d->type, vk_descriptor_type,
                    d->register_index, shader_visibility, vk_stage, flags, &binding_idx))
                return false;

            wined3d_type = wined3d_descriptor_type_from_vkd3d(d->type);
            if (!wined3d_shader_resource_bindings_add_binding(wined3d_bindings, shader_type,
                    wined3d_type, d->register_index, wined3d_shader_resource_type_from_vkd3d(d->resource_type),
                    wined3d_data_type_from_vkd3d(d->resource_data_type), binding_idx))
                return false;

            if (d->type == VKD3D_SHADER_DESCRIPTOR_TYPE_UAV
                    && (d->flags & VKD3D_SHADER_DESCRIPTOR_INFO_FLAG_UAV_COUNTER))
            {
                if (!shader_spirv_resource_bindings_add_uav_counter_binding(bindings,
                        d->register_index, shader_visibility, vk_stage, &binding_idx))
                    return false;
                if (!wined3d_shader_resource_bindings_add_binding(wined3d_bindings,
                        shader_type, WINED3D_SHADER_DESCRIPTOR_TYPE_UAV_COUNTER, d->register_index,
                        WINED3D_SHADER_RESOURCE_BUFFER, WINED3D_DATA_UINT, binding_idx))
                    return false;
            }
        }

        /* vkd3d-shader doesn't scan the uniform buffers we use for parameters.
         * It can't really be reasonably modified to do so either, because
         * parameters are specified in terms of the destination environment
         * (SPIRV binding set and index). Add them manually here.
         *
         * Note that vkd3d-shader will ignore the extra binding specified in
         * struct shader_spirv_resource_bindings, but we use it elsewhere. */

        if (shader->source_type == VKD3D_SHADER_SOURCE_D3D_BYTECODE)
        {
            if (!shader_spirv_resource_bindings_add_binding(bindings, VKD3D_SHADER_DESCRIPTOR_TYPE_CBV,
                    VK_DESCRIPTOR_TYPE_UNIFORM_BUFFER, WINED3D_FFP_CONSTANTS_EXTRA_REGISTER,
                    shader_visibility, vk_stage, VKD3D_SHADER_BINDING_FLAG_BUFFER, &binding_idx))
                return false;
            if (!wined3d_shader_resource_bindings_add_binding(wined3d_bindings, shader_type,
                    WINED3D_SHADER_DESCRIPTOR_TYPE_CBV, WINED3D_FFP_CONSTANTS_EXTRA_REGISTER,
                    WINED3D_SHADER_RESOURCE_BUFFER, WINED3D_DATA_FLOAT, binding_idx))
                return false;
            bindings->ffp_extra_binding[shader_type] = binding_idx;
        }
    }

    return true;
}

Referenced by shader_spirv_apply_compute_state(), and shader_spirv_apply_draw_state().

◆ shader_spirv_scan_shader()

static void shader_spirv_scan_shader	(	struct wined3d_shader *	shader,
		struct vkd3d_shader_scan_descriptor_info *	descriptor_info,
		struct vkd3d_shader_scan_signature_info *	signature_info
	)

static

Definition at line 755 of file shader_spirv.c.

{
    struct vkd3d_shader_compile_info info;
    char *messages;
    int ret;

    memset(descriptor_info, 0, sizeof(*descriptor_info));
    descriptor_info->type = VKD3D_SHADER_STRUCTURE_TYPE_SCAN_DESCRIPTOR_INFO;

    if (signature_info)
    {
        memset(signature_info, 0, sizeof(*signature_info));
        signature_info->type = VKD3D_SHADER_STRUCTURE_TYPE_SCAN_SIGNATURE_INFO;
        descriptor_info->next = signature_info;
    }

    info.type = VKD3D_SHADER_STRUCTURE_TYPE_COMPILE_INFO;
    info.next = descriptor_info;
    if (shader->source_type == VKD3D_SHADER_SOURCE_D3D_BYTECODE)
    {
        info.source.code = shader->function;
        info.source.size = shader->functionLength;
    }
    else
    {
        info.source.code = shader->byte_code;
        info.source.size = shader->byte_code_size;
    }
    info.source_type = shader->source_type;
    info.target_type = VKD3D_SHADER_TARGET_SPIRV_BINARY;
    info.options = spirv_compile_options;
    info.option_count = ARRAY_SIZE(spirv_compile_options);
    info.log_level = VKD3D_SHADER_LOG_WARNING;
    info.source_name = NULL;

    if ((ret = vkd3d_shader_scan(&info, &messages)) < 0)
        ERR("Failed to scan shader, ret %d.\n", ret);
    if (messages && *messages && FIXME_ON(d3d_shader))
    {
        const char *ptr, *end, *line;

        FIXME("Shader log:\n");
        ptr = messages;
        end = ptr + strlen(ptr);
        while ((line = wined3d_get_line(&ptr, end)))
        {
            FIXME("    %.*s", (int)(ptr - line), line);
        }
        FIXME("\n");
    }
    vkd3d_shader_free_messages(messages);
}

Referenced by shader_spirv_precompile(), and shader_spirv_precompile_compute().

◆ shader_spirv_update_float_pixel_constants()

static void shader_spirv_update_float_pixel_constants	(	struct wined3d_device *	device,
		UINT	start,
		UINT	count
	)

static

Definition at line 953 of file shader_spirv.c.

{
    WARN("Not implemented.\n");
}

◆ shader_spirv_update_float_vertex_constants()

static void shader_spirv_update_float_vertex_constants	(	struct wined3d_device *	device,
		UINT	start,
		UINT	count
	)

static

Definition at line 948 of file shader_spirv.c.

{
    WARN("Not implemented.\n");
}

◆ spirv_fragment_pipe_vk_fp_alloc()

static void * spirv_fragment_pipe_vk_fp_alloc	(	const struct wined3d_shader_backend_ops *	shader_backend,
		void *	shader_priv
	)

static

Definition at line 1254 of file shader_spirv.c.

{
    if (shader_backend != &spirv_shader_backend_vk)
    {
        FIXME("SPIR-V fragment pipe without SPIR-V shader backend not implemented.\n");
        return NULL;
    }

    return shader_priv;
}

◆ spirv_fragment_pipe_vk_fp_alloc_context_data()

static BOOL spirv_fragment_pipe_vk_fp_alloc_context_data ( struct wined3d_context * context )

static

Definition at line 1270 of file shader_spirv.c.

{
    return TRUE;
}

◆ spirv_fragment_pipe_vk_fp_apply_draw_state()

static void spirv_fragment_pipe_vk_fp_apply_draw_state	(	struct wined3d_context *	context,
		const struct wined3d_state *	state
	)

static

Definition at line 1232 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_fragment_pipe_vk_fp_disable()

static void spirv_fragment_pipe_vk_fp_disable ( const struct wined3d_context * context )

static

Definition at line 1238 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_fragment_pipe_vk_fp_free()

static void spirv_fragment_pipe_vk_fp_free	(	struct wined3d_device *	device,
		struct wined3d_context *	context
	)

static

Definition at line 1265 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_fragment_pipe_vk_fp_free_context_data()

static void spirv_fragment_pipe_vk_fp_free_context_data ( struct wined3d_context * context )

static

Definition at line 1275 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_fragment_pipe_vk_fp_get_caps()

static void spirv_fragment_pipe_vk_fp_get_caps	(	const struct wined3d_adapter *	adapter,
		struct fragment_caps *	caps
	)

static

Definition at line 1243 of file shader_spirv.c.

{
    memset(caps, 0, sizeof(*caps));
    caps->max_blend_stages = WINED3D_MAX_FFP_TEXTURES;
}

◆ spirv_fragment_pipe_vk_fp_get_emul_mask()

static unsigned int spirv_fragment_pipe_vk_fp_get_emul_mask ( const struct wined3d_adapter * adapter )

static

Definition at line 1249 of file shader_spirv.c.

{
    return 0;
}

◆ spirv_vertex_pipe_vk_vp_alloc()

static void * spirv_vertex_pipe_vk_vp_alloc	(	const struct wined3d_shader_backend_ops *	shader_backend,
		void *	shader_priv
	)

static

Definition at line 1189 of file shader_spirv.c.

{
    if (shader_backend != &spirv_shader_backend_vk)
    {
        FIXME("SPIR-V vertex pipe without SPIR-V shader backend not implemented.\n");
        return NULL;
    }

    return shader_priv;
}

◆ spirv_vertex_pipe_vk_vp_apply_draw_state()

static void spirv_vertex_pipe_vk_vp_apply_draw_state	(	struct wined3d_context *	context,
		const struct wined3d_state *	state
	)

static

Definition at line 1168 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_vertex_pipe_vk_vp_disable()

static void spirv_vertex_pipe_vk_vp_disable ( const struct wined3d_context * context )

static

Definition at line 1173 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_vertex_pipe_vk_vp_free()

static void spirv_vertex_pipe_vk_vp_free	(	struct wined3d_device *	device,
		struct wined3d_context *	context
	)

static

Definition at line 1200 of file shader_spirv.c.

{
    /* Nothing to do. */
}

◆ spirv_vertex_pipe_vk_vp_get_caps()

static void spirv_vertex_pipe_vk_vp_get_caps	(	const struct wined3d_adapter *	adapter,
		struct wined3d_vertex_caps *	caps
	)

static

Definition at line 1178 of file shader_spirv.c.

{
    memset(caps, 0, sizeof(*caps));
    caps->emulated_flatshading = true;
}

◆ spirv_vertex_pipe_vk_vp_get_emul_mask()

static unsigned int spirv_vertex_pipe_vk_vp_get_emul_mask ( const struct wined3d_adapter * adapter )

static

Definition at line 1184 of file shader_spirv.c.

{
    return 0;
}

◆ vk_descriptor_type_from_vkd3d()

static VkDescriptorType vk_descriptor_type_from_vkd3d	(	enum vkd3d_shader_descriptor_type	type,
		enum vkd3d_shader_resource_type	resource_type
	)

static

Definition at line 573 of file shader_spirv.c.

{
    switch (type)
    {
        case VKD3D_SHADER_DESCRIPTOR_TYPE_CBV:
            return VK_DESCRIPTOR_TYPE_UNIFORM_BUFFER;

        case VKD3D_SHADER_DESCRIPTOR_TYPE_SRV:
            if (resource_type == VKD3D_SHADER_RESOURCE_BUFFER)
                return VK_DESCRIPTOR_TYPE_UNIFORM_TEXEL_BUFFER;
            return VK_DESCRIPTOR_TYPE_SAMPLED_IMAGE;

        case VKD3D_SHADER_DESCRIPTOR_TYPE_UAV:
            if (resource_type == VKD3D_SHADER_RESOURCE_BUFFER)
                return VK_DESCRIPTOR_TYPE_STORAGE_TEXEL_BUFFER;
            return VK_DESCRIPTOR_TYPE_STORAGE_IMAGE;

        case VKD3D_SHADER_DESCRIPTOR_TYPE_SAMPLER:
            return VK_DESCRIPTOR_TYPE_SAMPLER;

        default:
            FIXME("Unhandled descriptor type %#x.\n", type);
            return ~0u;
    }
}

Referenced by shader_spirv_resource_bindings_init().

◆ WINE_DEFAULT_DEBUG_CHANNEL()

WINE_DEFAULT_DEBUG_CHANNEL ( d3d_shader )

◆ wined3d_data_type_from_vkd3d()

static enum wined3d_data_type wined3d_data_type_from_vkd3d ( enum vkd3d_shader_resource_data_type t )

static

Definition at line 627 of file shader_spirv.c.

{
    switch (t)
    {
        case VKD3D_SHADER_RESOURCE_DATA_UNORM:
            return WINED3D_DATA_UNORM;
        case VKD3D_SHADER_RESOURCE_DATA_SNORM:
            return WINED3D_DATA_SNORM;
        case VKD3D_SHADER_RESOURCE_DATA_INT:
            return WINED3D_DATA_INT;
        case VKD3D_SHADER_RESOURCE_DATA_UINT:
            return WINED3D_DATA_UINT;
        case VKD3D_SHADER_RESOURCE_DATA_FLOAT:
            return WINED3D_DATA_FLOAT;
        case VKD3D_SHADER_RESOURCE_DATA_MIXED:
            return WINED3D_DATA_UINT;
        default:
            FIXME("Unhandled resource data type %#x.\n", t);
            return WINED3D_DATA_FLOAT;
    }
}

Referenced by shader_spirv_resource_bindings_init().

◆ wined3d_descriptor_type_from_vkd3d()

static enum wined3d_shader_descriptor_type wined3d_descriptor_type_from_vkd3d ( enum vkd3d_shader_descriptor_type type )

static

Definition at line 600 of file shader_spirv.c.

{
    switch (type)
    {
        case VKD3D_SHADER_DESCRIPTOR_TYPE_CBV:
            return WINED3D_SHADER_DESCRIPTOR_TYPE_CBV;

        case VKD3D_SHADER_DESCRIPTOR_TYPE_SRV:
            return WINED3D_SHADER_DESCRIPTOR_TYPE_SRV;

        case VKD3D_SHADER_DESCRIPTOR_TYPE_UAV:
            return WINED3D_SHADER_DESCRIPTOR_TYPE_UAV;

        case VKD3D_SHADER_DESCRIPTOR_TYPE_SAMPLER:
            return WINED3D_SHADER_DESCRIPTOR_TYPE_SAMPLER;

        default:
            FIXME("Unhandled descriptor type %#x.\n", type);
            return ~0u;
    }
}

Referenced by shader_spirv_resource_bindings_init().

◆ wined3d_shader_resource_bindings_add_binding()

static bool wined3d_shader_resource_bindings_add_binding	(	struct wined3d_shader_resource_bindings *	bindings,
		enum wined3d_shader_type	shader_type,
		enum wined3d_shader_descriptor_type	shader_descriptor_type,
		size_t	resource_idx,
		enum wined3d_shader_resource_type	resource_type,
		enum wined3d_data_type	resource_data_type,
		size_t	binding_idx
	)

static

Definition at line 549 of file shader_spirv.c.

{
    struct wined3d_shader_resource_binding *binding;
    SIZE_T binding_count = bindings->count;

    if (!wined3d_array_reserve((void **)&bindings->bindings, &bindings->size,
            binding_count + 1, sizeof(*bindings->bindings)))
        return false;

    binding = &bindings->bindings[binding_count];
    binding->shader_type = shader_type;
    binding->shader_descriptor_type = shader_descriptor_type;
    binding->resource_idx = resource_idx;
    binding->resource_type = resource_type;
    binding->resource_data_type = resource_data_type;
    binding->binding_idx = binding_idx;
    ++bindings->count;

    return true;
}

Referenced by shader_spirv_resource_bindings_init().

◆ wined3d_shader_resource_type_from_vkd3d()

static enum wined3d_shader_resource_type wined3d_shader_resource_type_from_vkd3d ( enum vkd3d_shader_resource_type t )

static

Definition at line 622 of file shader_spirv.c.

{
    return (enum wined3d_shader_resource_type)t;
}

Referenced by shader_spirv_resource_bindings_init().

◆ wined3d_spirv_fragment_pipe_init_vk()

const struct wined3d_fragment_pipe_ops * wined3d_spirv_fragment_pipe_init_vk ( void )

Definition at line 1311 of file shader_spirv.c.

{
    return &spirv_fragment_pipe_vk;
}

Referenced by wined3d_adapter_vk_init().

◆ wined3d_spirv_shader_backend_init_vk()

const struct wined3d_shader_backend_ops * wined3d_spirv_shader_backend_init_vk ( void )

Definition at line 1161 of file shader_spirv.c.

{
    TRACE("Using %s.\n", vkd3d_shader_get_version(NULL, NULL));

    return &spirv_shader_backend_vk;
}

Referenced by wined3d_adapter_vk_init().

◆ wined3d_spirv_vertex_pipe_init_vk()

const struct wined3d_vertex_pipe_ops * wined3d_spirv_vertex_pipe_init_vk ( void )

Definition at line 1227 of file shader_spirv.c.

{
    return &spirv_vertex_pipe_vk;
}

Referenced by wined3d_adapter_vk_init().

Variable Documentation

◆ spirv_compile_options

const struct vkd3d_shader_compile_option spirv_compile_options[]

static

Initial value:

=
{
    {VKD3D_SHADER_COMPILE_OPTION_API_VERSION, VKD3D_SHADER_API_VERSION_1_7},
    {VKD3D_SHADER_COMPILE_OPTION_WRITE_TESS_GEOM_POINT_SIZE, 0},
}

Definition at line 27 of file shader_spirv.c.

Referenced by shader_spirv_compile_shader(), and shader_spirv_scan_shader().

◆ spirv_fragment_pipe_vk

const struct wined3d_fragment_pipe_ops spirv_fragment_pipe_vk

static

Initial value:

=
{
    .fp_apply_draw_state = spirv_fragment_pipe_vk_fp_apply_draw_state,
    .fp_disable = spirv_fragment_pipe_vk_fp_disable,
    .get_caps = spirv_fragment_pipe_vk_fp_get_caps,
    .get_emul_mask = spirv_fragment_pipe_vk_fp_get_emul_mask,
    .alloc_private = spirv_fragment_pipe_vk_fp_alloc,
    .free_private = spirv_fragment_pipe_vk_fp_free,
    .allocate_context_data = spirv_fragment_pipe_vk_fp_alloc_context_data,
    .free_context_data = spirv_fragment_pipe_vk_fp_free_context_data,
    .color_fixup_supported = shader_spirv_color_fixup_supported,
    .states = spirv_fragment_pipe_vk_fp_states,
}

Definition at line 1297 of file shader_spirv.c.

Referenced by wined3d_spirv_fragment_pipe_init_vk().

◆ spirv_fragment_pipe_vk_fp_states

const struct wined3d_state_entry_template spirv_fragment_pipe_vk_fp_states[]

static

Initial value:

=
{
    {STATE_RENDER(WINED3D_RS_SHADEMODE),         {STATE_RENDER(WINED3D_RS_SHADEMODE),         state_nop}},
    {STATE_RENDER(WINED3D_RS_ALPHATESTENABLE),   {STATE_RENDER(WINED3D_RS_ALPHATESTENABLE),   state_nop}},
    {STATE_RENDER(WINED3D_RS_ALPHAFUNC),         {STATE_RENDER(WINED3D_RS_ALPHAFUNC),         state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGENABLE),         {STATE_RENDER(WINED3D_RS_FOGENABLE),         state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGCOLOR),          {STATE_RENDER(WINED3D_RS_FOGCOLOR),          state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGTABLEMODE),      {STATE_RENDER(WINED3D_RS_FOGTABLEMODE),      state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGSTART),          {STATE_RENDER(WINED3D_RS_FOGSTART),          state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGEND),            {STATE_RENDER(WINED3D_RS_FOGEND),            state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGDENSITY),        {STATE_RENDER(WINED3D_RS_FOGDENSITY),        state_nop}},
    {STATE_RENDER(WINED3D_RS_FOGVERTEXMODE),     {STATE_RENDER(WINED3D_RS_FOGVERTEXMODE),     state_nop}},
    {STATE_RENDER(WINED3D_RS_POINTSPRITEENABLE), {STATE_RENDER(WINED3D_RS_POINTSPRITEENABLE), state_nop}},
    {STATE_RENDER(WINED3D_RS_SRGBWRITEENABLE),   {STATE_RENDER(WINED3D_RS_SRGBWRITEENABLE),   state_nop}},
    {0},
}

Definition at line 1280 of file shader_spirv.c.

◆ spirv_shader_backend_vk

static const struct wined3d_shader_backend_ops spirv_shader_backend_vk

static

Initial value:

=
{
    .shader_handle_instruction = shader_spirv_handle_instruction,
    .shader_precompile = shader_spirv_precompile,
    .shader_apply_draw_state = shader_spirv_apply_draw_state,
    .shader_apply_compute_state = shader_spirv_apply_compute_state,
    .shader_disable = shader_spirv_disable,
    .shader_update_float_vertex_constants = shader_spirv_update_float_vertex_constants,
    .shader_update_float_pixel_constants = shader_spirv_update_float_pixel_constants,
    .shader_destroy = shader_spirv_destroy,
    .shader_alloc_private = shader_spirv_alloc,
    .shader_free_private = shader_spirv_free,
    .shader_allocate_context_data = shader_spirv_allocate_context_data,
    .shader_free_context_data = shader_spirv_free_context_data,
    .shader_init_context_state = shader_spirv_init_context_state,
    .shader_get_caps = shader_spirv_get_caps,
    .shader_color_fixup_supported = shader_spirv_color_fixup_supported,
    .shader_compile = shader_spirv_compile,
}

Definition at line 25 of file shader_spirv.c.

Referenced by shader_spirv_alloc(), spirv_fragment_pipe_vk_fp_alloc(), spirv_vertex_pipe_vk_vp_alloc(), and wined3d_spirv_shader_backend_init_vk().

◆ spirv_vertex_pipe_vk

const struct wined3d_vertex_pipe_ops spirv_vertex_pipe_vk

static

Initial value:

=
{
    .vp_apply_draw_state = spirv_vertex_pipe_vk_vp_apply_draw_state,
    .vp_disable = spirv_vertex_pipe_vk_vp_disable,
    .vp_get_caps = spirv_vertex_pipe_vk_vp_get_caps,
    .vp_get_emul_mask = spirv_vertex_pipe_vk_vp_get_emul_mask,
    .vp_alloc = spirv_vertex_pipe_vk_vp_alloc,
    .vp_free = spirv_vertex_pipe_vk_vp_free,
    .vp_states = spirv_vertex_pipe_vk_vp_states,
}

Definition at line 1216 of file shader_spirv.c.

Referenced by wined3d_spirv_vertex_pipe_init_vk().

◆ spirv_vertex_pipe_vk_vp_states

const struct wined3d_state_entry_template spirv_vertex_pipe_vk_vp_states[]

static

Initial value:

=
{
    {STATE_RENDER(WINED3D_RS_CLIPPING),                 {STATE_RENDER(WINED3D_RS_CLIPPING),                 state_nop}},
    {STATE_RENDER(WINED3D_RS_CLIPPLANEENABLE),          {STATE_RENDER(WINED3D_RS_CLIPPLANEENABLE),          state_nop}},
    {STATE_RENDER(WINED3D_RS_POINTSIZE),                {STATE_RENDER(WINED3D_RS_POINTSIZE),                state_nop}},
    {STATE_RENDER(WINED3D_RS_POINTSIZE_MIN),            {STATE_RENDER(WINED3D_RS_POINTSIZE_MIN),            state_nop}},
    {STATE_RENDER(WINED3D_RS_POINTSIZE_MAX),            {STATE_RENDER(WINED3D_RS_POINTSIZE_MAX),            state_nop}},
    {STATE_SHADER(WINED3D_SHADER_TYPE_VERTEX),          {STATE_SHADER(WINED3D_SHADER_TYPE_VERTEX),          state_nop}},
    {0},
}

Definition at line 1205 of file shader_spirv.c.

Variables
static const struct wined3d_shader_backend_ops	spirv_shader_backend_vk

static const struct vkd3d_shader_compile_option	spirv_compile_options []

static const struct wined3d_state_entry_template	spirv_vertex_pipe_vk_vp_states []

static const struct wined3d_vertex_pipe_ops	spirv_vertex_pipe_vk

static const struct wined3d_state_entry_template	spirv_fragment_pipe_vk_fp_states []

static const struct wined3d_fragment_pipe_ops	spirv_fragment_pipe_vk

Classes

Macros

Functions

Variables

Macro Definition Documentation

◆ MAX_SM1_INTER_STAGE_VARYINGS

Function Documentation

◆ fill_ps_parameters()

◆ shader_spirv_alloc()

◆ shader_spirv_allocate_context_data()

◆ shader_spirv_apply_compute_state()

◆ shader_spirv_apply_draw_state()

◆ shader_spirv_color_fixup_supported()

◆ shader_spirv_compile()

◆ shader_spirv_compile_arguments_init()

◆ shader_spirv_compile_shader()

◆ shader_spirv_destroy()

◆ shader_spirv_destroy_compute_vk()

◆ shader_spirv_disable()

◆ shader_spirv_find_compute_program_vk()

◆ shader_spirv_find_graphics_program_variant_vk()

◆ shader_spirv_free()

◆ shader_spirv_free_context_data()

◆ shader_spirv_get_caps()

◆ shader_spirv_handle_instruction()

◆ shader_spirv_init_compile_args()

◆ shader_spirv_init_context_state()

◆ shader_spirv_init_shader_interface_vk()

◆ shader_spirv_invalidate_compute_program()

◆ shader_spirv_invalidate_contexts_compute_program()

◆ shader_spirv_invalidate_contexts_graphics_program_variant()

◆ shader_spirv_invalidate_graphics_program_variant()

◆ shader_spirv_precompile()

◆ shader_spirv_precompile_compute()

◆ shader_spirv_resource_bindings_add_binding()

◆ shader_spirv_resource_bindings_add_uav_counter_binding()

◆ shader_spirv_resource_bindings_add_vk_binding()

◆ shader_spirv_resource_bindings_cleanup()

◆ shader_spirv_resource_bindings_init()

◆ shader_spirv_scan_shader()

◆ shader_spirv_update_float_pixel_constants()

◆ shader_spirv_update_float_vertex_constants()

◆ spirv_fragment_pipe_vk_fp_alloc()

◆ spirv_fragment_pipe_vk_fp_alloc_context_data()

◆ spirv_fragment_pipe_vk_fp_apply_draw_state()

◆ spirv_fragment_pipe_vk_fp_disable()

◆ spirv_fragment_pipe_vk_fp_free()

◆ spirv_fragment_pipe_vk_fp_free_context_data()

◆ spirv_fragment_pipe_vk_fp_get_caps()

◆ spirv_fragment_pipe_vk_fp_get_emul_mask()

◆ spirv_vertex_pipe_vk_vp_alloc()

◆ spirv_vertex_pipe_vk_vp_apply_draw_state()

◆ spirv_vertex_pipe_vk_vp_disable()

◆ spirv_vertex_pipe_vk_vp_free()

◆ spirv_vertex_pipe_vk_vp_get_caps()

◆ spirv_vertex_pipe_vk_vp_get_emul_mask()

◆ vk_descriptor_type_from_vkd3d()

◆ WINE_DEFAULT_DEBUG_CHANNEL()

◆ wined3d_data_type_from_vkd3d()

◆ wined3d_descriptor_type_from_vkd3d()

◆ wined3d_shader_resource_bindings_add_binding()

◆ wined3d_shader_resource_type_from_vkd3d()

◆ wined3d_spirv_fragment_pipe_init_vk()

◆ wined3d_spirv_shader_backend_init_vk()

◆ wined3d_spirv_vertex_pipe_init_vk()

Variable Documentation

◆ spirv_compile_options

◆ spirv_fragment_pipe_vk

◆ spirv_fragment_pipe_vk_fp_states

◆ spirv_shader_backend_vk

◆ spirv_vertex_pipe_vk

◆ spirv_vertex_pipe_vk_vp_states
