vkd3d_shader_interface_info Struct Reference

#include <vkd3d_shader.h>

Collaboration diagram for vkd3d_shader_interface_info:
Collaboration graph
[legend]

Public Attributes

enum vkd3d_shader_structure_type type

const void * next

const struct vkd3d_shader_resource_binding * bindings

unsigned int binding_count

const struct vkd3d_shader_push_constant_buffer * push_constant_buffers

unsigned int push_constant_buffer_count

const struct vkd3d_shader_combined_resource_sampler * combined_samplers

unsigned int combined_sampler_count

const struct vkd3d_shader_uav_counter_binding * uav_counters

unsigned int uav_counter_count


Detailed Description

A chained structure describing the interface between a compiled shader and the target environment.

For example, when compiling Direct3D shader byte code to SPIR-V, this structure contains mappings from Direct3D descriptor registers to SPIR-V descriptor bindings.

This structure is optional. If omitted, vkd3d_shader_compile() will use a default mapping, in which resources are mapped to sequential bindings in register set 0.

This structure extends vkd3d_shader_compile_info.

This structure contains only input parameters.

Definition at line 1059 of file vkd3d_shader.h.

Member Data Documentation

◆ binding_count

unsigned int vkd3d_shader_interface_info::binding_count

Size, in elements, of bindings.

Definition at line 1069 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_get_descriptor_binding(), and vkd3d_uav_clear_state_init().

◆ bindings

const struct vkd3d_shader_resource_binding* vkd3d_shader_interface_info::bindings

Pointer to an array of bindings for shader resource descriptors.

Definition at line 1067 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_get_descriptor_binding(), and vkd3d_uav_clear_state_init().

◆ combined_sampler_count

unsigned int vkd3d_shader_interface_info::combined_sampler_count

Size, in elements, of combined_samplers.

Definition at line 1079 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_emit_combined_sampler_declarations(), spirv_compiler_find_combined_sampler(), spirv_compiler_has_combined_sampler_for_resource(), spirv_compiler_has_combined_sampler_for_sampler(), and vkd3d_uav_clear_state_init().

◆ combined_samplers

const struct vkd3d_shader_combined_resource_sampler* vkd3d_shader_interface_info::combined_samplers

Pointer to an array of bindings for combined samplers.

Definition at line 1077 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_emit_combined_sampler_declarations(), spirv_compiler_has_combined_sampler_for_resource(), spirv_compiler_has_combined_sampler_for_sampler(), and vkd3d_uav_clear_state_init().

◆ next

const void* vkd3d_shader_interface_info::next

Optional pointer to a structure containing further parameters.

Definition at line 1064 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_create(), and vkd3d_uav_clear_state_init().

◆ push_constant_buffer_count

unsigned int vkd3d_shader_interface_info::push_constant_buffer_count

Size, in elements, of push_constant_buffers.

Definition at line 1074 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_create(), and vkd3d_uav_clear_state_init().

◆ push_constant_buffers

const struct vkd3d_shader_push_constant_buffer* vkd3d_shader_interface_info::push_constant_buffers

Pointer to an array of bindings for push constant buffers.

Definition at line 1072 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_create(), and vkd3d_uav_clear_state_init().

◆ type

enum vkd3d_shader_structure_type vkd3d_shader_interface_info::type

Must be set to VKD3D_SHADER_STRUCTURE_TYPE_INTERFACE_INFO.

Definition at line 1062 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), and vkd3d_uav_clear_state_init().

◆ uav_counter_count

unsigned int vkd3d_shader_interface_info::uav_counter_count

Size, in elements, of uav_counters.

Definition at line 1084 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_get_descriptor_binding(), and vkd3d_uav_clear_state_init().

◆ uav_counters

const struct vkd3d_shader_uav_counter_binding* vkd3d_shader_interface_info::uav_counters

Pointer to an array of bindings for UAV counters.

Definition at line 1082 of file vkd3d_shader.h.

Referenced by d3d12_pipeline_state_init_compute(), d3d12_pipeline_state_init_graphics(), spirv_compiler_get_descriptor_binding(), and vkd3d_uav_clear_state_init().

The documentation for this struct was generated from the following file:
