d2d_device_context Struct Reference

#include <d2d1_private.h>

Collaboration diagram for d2d_device_context:
Collaboration graph
[legend]

Public Attributes

ID2D1DeviceContext6 ID2D1DeviceContext6_iface

ID2D1GdiInteropRenderTarget ID2D1GdiInteropRenderTarget_iface

IDWriteTextRenderer IDWriteTextRenderer_iface

IUnknown IUnknown_iface

LONG refcount

IUnknown * outer_unknown

const struct d2d_device_context_ops * ops

ID2D1Factory * factory

CRITICAL_SECTION * cs

struct d2d_device * device

ID3D11Device1 * d3d_device

ID3DDeviceContextState * d3d_state

struct {
   ID2D1Image *   object

   enum d2d_device_context_target_type   type

   union {
      struct d2d_bitmap *   bitmap

      struct d2d_command_list *   command_list

   }

   HDC   hdc

} target

struct d2d_shape_resources shape_resources [D2D_SHAPE_TYPE_COUNT]

ID3D11Buffer * vs_cb

ID3D11PixelShader * ps

ID3D11Buffer * ps_cb

ID3D11Buffer * ib

unsigned int vb_stride

ID3D11Buffer * vb

ID3D11RasterizerState * rs

ID3D11BlendState * bs

ID3D11SamplerState * sampler_states [D2D_SAMPLER_INTERPOLATION_MODE_COUNT][D2D_SAMPLER_EXTEND_MODE_COUNT][D2D_SAMPLER_EXTEND_MODE_COUNT]

struct d2d_error_state error

D2D1_DRAWING_STATE_DESCRIPTION1 drawing_state

IDWriteRenderingParams * text_rendering_params

IDWriteRenderingParams * default_text_rendering_params

D2D1_RENDER_TARGET_PROPERTIES desc

D2D1_SIZE_U pixel_size

struct d2d_clip_stack clip_stack

struct d2d_indexed_objects vertex_buffers


Detailed Description

Definition at line 173 of file d2d1_private.h.

Member Data Documentation

◆ bitmap

struct d2d_bitmap* d2d_device_context::bitmap

Definition at line 195 of file d2d1_private.h.

Referenced by d2d_d3d_create_render_target(), d2d_device_context_DrawImage(), and d2d_device_context_GetImageLocalBounds().

◆ bs

ID3D11BlendState* d2d_device_context::bs

Definition at line 208 of file d2d1_private.h.

Referenced by d2d_device_context_draw().

◆ clip_stack

struct d2d_clip_stack d2d_device_context::clip_stack

Definition at line 221 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆ command_list

struct d2d_command_list* d2d_device_context::command_list

Definition at line 196 of file d2d1_private.h.

◆ cs

CRITICAL_SECTION* d2d_device_context::cs

Definition at line 185 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆ d3d_device

ID3D11Device1* d2d_device_context::d3d_device

Definition at line 187 of file d2d1_private.h.

Referenced by d2d_device_context_CreateGradientStopCollection(), d2d_device_context_draw(), d2d_device_context_draw_geometry(), d2d_device_context_fill_geometry(), and d2d_device_context_init().

◆ d3d_state

ID3DDeviceContextState* d2d_device_context::d3d_state

Definition at line 188 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆ default_text_rendering_params

IDWriteRenderingParams* d2d_device_context::default_text_rendering_params

Definition at line 217 of file d2d1_private.h.

Referenced by d2d_device_context_init().

◆ desc

D2D1_RENDER_TARGET_PROPERTIES d2d_device_context::desc

Definition at line 219 of file d2d1_private.h.

Referenced by d2d_bitmap_render_target_init(), d2d_device_context_DrawText(), d2d_device_context_GetDpi(), d2d_device_context_GetPixelFormat(), d2d_device_context_GetSize(), d2d_device_context_init(), d2d_device_context_SetDpi(), d2d_text_renderer_DrawStrikethrough(), d2d_text_renderer_DrawUnderline(), and d2d_text_renderer_GetPixelsPerDip().

◆ device

struct d2d_device* d2d_device_context::device

Definition at line 186 of file d2d1_private.h.

Referenced by d2d_bitmap_render_target_init(), and d2d_device_context_init().

◆ drawing_state

D2D1_DRAWING_STATE_DESCRIPTION1 d2d_device_context::drawing_state

Definition at line 215 of file d2d1_private.h.

Referenced by d2d_device_context_draw_glyph_run_outline(), d2d_device_context_DrawText(), d2d_device_context_GetAntialiasMode(), d2d_device_context_GetTags(), d2d_device_context_GetTextAntialiasMode(), d2d_device_context_GetTransform(), d2d_device_context_init(), d2d_device_context_SaveDrawingState(), d2d_device_context_set_aa_mode_from_text_aa_mode(), d2d_text_renderer_DrawGlyphRun(), d2d_text_renderer_DrawStrikethrough(), and d2d_text_renderer_DrawUnderline().

◆ error

struct d2d_error_state d2d_device_context::error

Definition at line 214 of file d2d1_private.h.

◆ factory

ID2D1Factory* d2d_device_context::factory

Definition at line 184 of file d2d1_private.h.

Referenced by d2d_device_context_CreateGradientStopCollection(), d2d_device_context_CreateLayer(), d2d_device_context_CreateLinearGradientBrush(), d2d_device_context_CreateMesh(), d2d_device_context_CreateRadialGradientBrush(), d2d_device_context_CreateSolidColorBrush(), d2d_device_context_draw_glyph_run_outline(), d2d_device_context_DrawEllipse(), d2d_device_context_DrawRoundedRectangle(), d2d_device_context_FillEllipse(), d2d_device_context_FillRoundedRectangle(), d2d_device_context_GetFactory(), and d2d_device_context_init().

◆ hdc

HDC d2d_device_context::hdc

Definition at line 198 of file d2d1_private.h.

◆ ib

ID3D11Buffer* d2d_device_context::ib

Definition at line 204 of file d2d1_private.h.

Referenced by d2d_device_context_init().

◆ ID2D1DeviceContext6_iface

ID2D1DeviceContext6 d2d_device_context::ID2D1DeviceContext6_iface

Definition at line 175 of file d2d1_private.h.

Referenced by d2d_device_context_init(), d2d_text_renderer_DrawGlyphRun(), d2d_text_renderer_DrawStrikethrough(), d2d_text_renderer_DrawUnderline(), and impl_from_ID2D1DeviceContext().

◆ ID2D1GdiInteropRenderTarget_iface

ID2D1GdiInteropRenderTarget d2d_device_context::ID2D1GdiInteropRenderTarget_iface

Definition at line 176 of file d2d1_private.h.

Referenced by d2d_device_context_init(), and impl_from_ID2D1GdiInteropRenderTarget().

◆ IDWriteTextRenderer_iface

IDWriteTextRenderer d2d_device_context::IDWriteTextRenderer_iface

Definition at line 177 of file d2d1_private.h.

Referenced by d2d_device_context_DrawTextLayout(), d2d_device_context_init(), and impl_from_IDWriteTextRenderer().

◆ IUnknown_iface

IUnknown d2d_device_context::IUnknown_iface

Definition at line 178 of file d2d1_private.h.

Referenced by d2d_device_context_init(), and impl_from_IUnknown().

◆ object

ID2D1Image* d2d_device_context::object

Definition at line 191 of file d2d1_private.h.

Referenced by d2d_d3d_create_render_target(), and d2d_device_create_device_context().

◆ ops

const struct d2d_device_context_ops* d2d_device_context::ops

Definition at line 182 of file d2d1_private.h.

Referenced by d2d_bitmap_render_target_init(), d2d_d3d_create_render_target(), and d2d_device_context_init().

◆ outer_unknown

IUnknown* d2d_device_context::outer_unknown

Definition at line 181 of file d2d1_private.h.

Referenced by d2d_d3d_create_render_target(), d2d_device_context_init(), d2d_gdi_interop_render_target_AddRef(), d2d_gdi_interop_render_target_QueryInterface(), and d2d_gdi_interop_render_target_Release().

◆ pixel_size

D2D1_SIZE_U d2d_device_context::pixel_size

Definition at line 220 of file d2d1_private.h.

Referenced by d2d_bitmap_render_target_init(), d2d_device_context_draw(), d2d_device_context_GetImageLocalBounds(), d2d_device_context_GetPixelSize(), and d2d_device_context_GetSize().

◆ ps

ID3D11PixelShader* d2d_device_context::ps

Definition at line 202 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆ ps_cb

ID3D11Buffer* d2d_device_context::ps_cb

Definition at line 203 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆ refcount

LONG d2d_device_context::refcount

Definition at line 179 of file d2d1_private.h.

Referenced by d2d_device_context_init(), d2d_device_context_inner_AddRef(), and d2d_device_context_inner_Release().

◆ rs

ID3D11RasterizerState* d2d_device_context::rs

Definition at line 207 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆ sampler_states

ID3D11SamplerState* d2d_device_context::sampler_states[D2D_SAMPLER_INTERPOLATION_MODE_COUNT][D2D_SAMPLER_EXTEND_MODE_COUNT][D2D_SAMPLER_EXTEND_MODE_COUNT]

Definition at line 209 of file d2d1_private.h.

◆ shape_resources

struct d2d_shape_resources d2d_device_context::shape_resources[D2D_SHAPE_TYPE_COUNT]

Definition at line 200 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

◆

struct { ... } d2d_device_context::target

Referenced by d2d_device_context_draw(), d2d_gdi_interop_render_target_GetDC(), and d2d_gdi_interop_render_target_ReleaseDC().

◆ text_rendering_params

IDWriteRenderingParams* d2d_device_context::text_rendering_params

Definition at line 216 of file d2d1_private.h.

Referenced by d2d_device_context_GetTextRenderingParams(), d2d_device_context_SaveDrawingState(), and d2d_device_context_SetTextRenderingParams().

◆ type

enum d2d_device_context_target_type d2d_device_context::type

Definition at line 192 of file d2d1_private.h.

◆ vb

ID3D11Buffer* d2d_device_context::vb

Definition at line 206 of file d2d1_private.h.

Referenced by d2d_device_context_init().

◆ vb_stride

unsigned int d2d_device_context::vb_stride

Definition at line 205 of file d2d1_private.h.

Referenced by d2d_device_context_init().

◆ vertex_buffers

struct d2d_indexed_objects d2d_device_context::vertex_buffers

Definition at line 223 of file d2d1_private.h.

◆ vs_cb

ID3D11Buffer* d2d_device_context::vs_cb

Definition at line 201 of file d2d1_private.h.

Referenced by d2d_device_context_draw(), and d2d_device_context_init().

The documentation for this struct was generated from the following file:
