#include <vkd3d_shader_private.h>

Collaboration diagram for vkd3d_shader_register:

[legend]

Public Attributes
enum vkd3d_shader_register_type	type

enum vkd3d_shader_register_precision	precision

bool	non_uniform

enum vkd3d_data_type	data_type

struct vkd3d_shader_register_index	idx [3]

unsigned int	idx_count

enum vsir_dimension	dimension

unsigned int	alignment

union {
uint32_t immconst_u32 [VKD3D_VEC4_SIZE]

float immconst_f32 [VKD3D_VEC4_SIZE]

uint64_t immconst_u64 [VKD3D_DVEC2_SIZE]

double immconst_f64 [VKD3D_DVEC2_SIZE]

unsigned fp_body_idx

}	u

Detailed Description

Definition at line 941 of file vkd3d_shader_private.h.

Member Data Documentation

◆ alignment

unsigned int vkd3d_shader_register::alignment

Definition at line 951 of file vkd3d_shader_private.h.

◆ data_type

enum vkd3d_data_type vkd3d_shader_register::data_type

Definition at line 946 of file vkd3d_shader_private.h.

◆ dimension

enum vsir_dimension vkd3d_shader_register::dimension

Definition at line 949 of file vkd3d_shader_private.h.

◆ fp_body_idx

unsigned vkd3d_shader_register::fp_body_idx

Definition at line 958 of file vkd3d_shader_private.h.

◆ idx

struct vkd3d_shader_register_index vkd3d_shader_register::idx[3]

Definition at line 947 of file vkd3d_shader_private.h.

Referenced by spirv_compiler_emit_default_control_point_phase(), spirv_compiler_emit_input(), and vkd3d_symbol_make_combined_sampler().

◆ idx_count

unsigned int vkd3d_shader_register::idx_count

Definition at line 948 of file vkd3d_shader_private.h.

Referenced by shader_dst_param_io_init().

◆ immconst_f32

float vkd3d_shader_register::immconst_f32[VKD3D_VEC4_SIZE]

Definition at line 955 of file vkd3d_shader_private.h.

◆ immconst_f64

double vkd3d_shader_register::immconst_f64[VKD3D_DVEC2_SIZE]

Definition at line 957 of file vkd3d_shader_private.h.

◆ immconst_u32

uint32_t vkd3d_shader_register::immconst_u32[VKD3D_VEC4_SIZE]

Definition at line 954 of file vkd3d_shader_private.h.

Referenced by sm6_parser_emit_reg_composite_construct().

◆ immconst_u64

uint64_t vkd3d_shader_register::immconst_u64[VKD3D_DVEC2_SIZE]

Definition at line 956 of file vkd3d_shader_private.h.

◆ non_uniform

bool vkd3d_shader_register::non_uniform

Definition at line 945 of file vkd3d_shader_private.h.

Referenced by spirv_compiler_prepare_image().

◆ precision

enum vkd3d_shader_register_precision vkd3d_shader_register::precision

Definition at line 944 of file vkd3d_shader_private.h.

◆ type

enum vkd3d_shader_register_type vkd3d_shader_register::type

Definition at line 943 of file vkd3d_shader_private.h.

Referenced by spirv_compiler_prepare_image(), and vkd3d_symbol_make_combined_sampler().

◆

union { ... } vkd3d_shader_register::u
