#include <vkd3d.h>
Public Attributes | |
| enum vkd3d_structure_type | type |
| const void * | next |
| D3D_FEATURE_LEVEL | minimum_feature_level |
| struct vkd3d_instance * | instance |
| const struct vkd3d_instance_create_info * | instance_create_info |
| VkPhysicalDevice | vk_physical_device |
| const char *const * | device_extensions |
| uint32_t | device_extension_count |
| IUnknown * | parent |
| LUID | adapter_luid |
Detailed Description
Member Data Documentation
◆ adapter_luid
| LUID vkd3d_device_create_info::adapter_luid |
The adapter LUID to be set for the device. This is not used by vkd3d except for being returned by GetAdapterLuid.
Definition at line 293 of file vkd3d.h.
Referenced by d3d12_device_init(), and D3D12CreateDevice().
◆ device_extension_count
| uint32_t vkd3d_device_create_info::device_extension_count |
The number of elements in the device_extensions array.
Definition at line 282 of file vkd3d.h.
Referenced by D3D12CreateDevice(), vkd3d_check_device_extensions(), and vkd3d_create_vk_device().
◆ device_extensions
A list of Vulkan device extensions to request. They are intended as required, so device creation will fail if any of them is not available.
Definition at line 280 of file vkd3d.h.
Referenced by D3D12CreateDevice(), vkd3d_check_device_extensions(), and vkd3d_create_vk_device().
◆ instance
| struct vkd3d_instance* vkd3d_device_create_info::instance |
The vkd3d instance to use to create a device. Either this or instance_create_info must be set.
Definition at line 261 of file vkd3d.h.
Referenced by D3D12CreateDevice(), and vkd3d_create_device().
◆ instance_create_info
| const struct vkd3d_instance_create_info* vkd3d_device_create_info::instance_create_info |
The parameters used to create an instance, which is then used to create a device. Either this or instance must be set.
Definition at line 266 of file vkd3d.h.
Referenced by D3D12CreateDevice(), and vkd3d_create_device().
◆ minimum_feature_level
| D3D_FEATURE_LEVEL vkd3d_device_create_info::minimum_feature_level |
The minimum feature level to request. Device creation will fail with E_INVALIDARG if the Vulkan device doesn't have the features needed to fulfill the request.
Definition at line 255 of file vkd3d.h.
Referenced by D3D12CreateDevice(), vkd3d_create_device(), and vkd3d_init_device_caps().
◆ next
Optional pointer to a structure containing further parameters.
Definition at line 251 of file vkd3d.h.
Referenced by D3D12CreateDevice(), vkd3d_check_device_extensions(), and vkd3d_create_vk_device().
◆ parent
| IUnknown* vkd3d_device_create_info::parent |
An object to be set as the device parent. This is not used by vkd3d except for being returned by vkd3d_get_device_parent.
Definition at line 288 of file vkd3d.h.
Referenced by d3d12_device_init(), and D3D12CreateDevice().
◆ type
| enum vkd3d_structure_type vkd3d_device_create_info::type |
Must be set to VKD3D_STRUCTURE_TYPE_DEVICE_CREATE_INFO.
Definition at line 249 of file vkd3d.h.
Referenced by D3D12CreateDevice(), and vkd3d_create_device().
◆ vk_physical_device
| VkPhysicalDevice vkd3d_device_create_info::vk_physical_device |
The Vulkan physical device to use. If it is NULL, the first physical device found is used, prioritizing discrete GPUs over integrated GPUs and integrated GPUs over all the others.
This parameter can be overridden by setting environment variable VKD3D_VULKAN_DEVICE.
Definition at line 274 of file vkd3d.h.
Referenced by D3D12CreateDevice(), and vkd3d_create_vk_device().
The documentation for this struct was generated from the following file:
- sdk/lib/vkd3d/include/vkd3d.h
